pDT-sgRNA-XMAS-2x
(Plasmid #164414)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 164414 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pUC19
  • Vector type
    Mammalian Expression, CRISPR, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    sgRNA
  • Alt name
    single guide RNA
  • gRNA/shRNA sequence
    pEF-XMAS-2Xstop, and non-targeted
  • Promoter U6

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BbsI (unknown if destroyed)
  • 3′ cloning site BbsI (unknown if destroyed)
  • 5′ sequencing primer TGTAAAACGACGGCCAGT
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pDT-sgRNA-XMAS-2x was a gift from Xiao Wang (Addgene plasmid # 164414 ; http://n2t.net/addgene:164414 ; RRID:Addgene_164414)

  • For your References section:

    A Cas9-mediated adenosine transient reporter enables enrichment of ABE-targeted cells. Brookhouser N, Nguyen T, Tekel SJ, Standage-Beier K, Wang X, Brafman DA. BMC Biol. 2020 Dec 14;18(1):193. doi: 10.1186/s12915-020-00929-7. 10.1186/s12915-020-00929-7 PubMed 33317513
