pBad-PhoCl2f
(Plasmid #164036)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 164036 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBad/HisB
  • Backbone size w/o insert (bp) 4076
  • Total vector size (bp) 4802
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PhoCl2f
  • Insert Size (bp)
    726
  • Promoter araBad promotor
  • Tag / Fusion Protein
    • His tag, T7 tag, Xpress Tag (N terminal on backbone)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer ATG CCATAGCATTTTTATCC
  • 3′ sequencing primer CCTGATACAGATTAAATC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBad-PhoCl2f was a gift from Robert Campbell (Addgene plasmid # 164036 ; http://n2t.net/addgene:164036 ; RRID:Addgene_164036)

  • For your References section:

    Photocleavable proteins that undergo fast and efficient dissociation. Lu X, Wen Y, Zhang S, Zhang W, Chen Y, Shen Y, Lemieux MJ, Campbell RE. Chem Sci. 2021 May 31;12(28):9658-9672. doi: 10.1039/d1sc01059j. eCollection 2021 Jul 21. 10.1039/d1sc01059j PubMed 34349937
