PKG I alpha WT
(Plasmid #16390)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 16390 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pHACE
  • Backbone size w/o insert (bp) 5400
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PKG1 alpha
  • Alt name
    PKG 1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2015
  • Entrez Gene
    PRKG1 (a.k.a. AAT8, PKG, PKG1, PRKG1B, PRKGR1B, cGK, cGK 1, cGK1, cGKI, cGKI-BETA, cGKI-alpha)
  • Tag / Fusion Protein
    • HA (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer CMV-F
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The PKG I alpha insert contains an EF insertion after the starting methionine and I537V mutation compared to the listed reference sequence.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PKG I alpha WT was a gift from Bernard Weinstein (Addgene plasmid # 16390 ; http://n2t.net/addgene:16390 ; RRID:Addgene_16390)

  • For your References section:

    Vasodilator-stimulated phosphoprotein (VASP) phosphorylation provides a biomarker for the action of exisulind and related agents that activate protein kinase G. Deguchi A, Soh JW, Li H, Pamukcu R, Thompson WJ, Weinstein IB. Mol Cancer Ther. 2002 Aug . 1(10):803-9. PubMed 12492113
