6VYC
(Plasmid #162266)

Print

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 162266 Standard format: Plasmid sent in bacteria as agar stab 1 $85 *
Add to Cart

* Log in to view industry pricing.

Backbone

  • Vector backbone
    pFBOH-MHL
  • Backbone manufacturer
    SGC (Addgene Plasmid #62304)
  • Vector type
    Baculovirus Expresssion

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    WDR91
  • Alt name
    PDB: 6VYC, 8SHJ, 8T55
  • Alt name
    PBC019-H10_C244404
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1023
  • Entrez Gene
    WDR91 (a.k.a. HSPC049, SORF-1, SORF1)
  • Promoter Polyhedrin
  • Tag / Fusion Protein
    • 6xHis-TEV (N terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer pFBOH-fwd (5'-CCGGATTATTCATACCGTCCCACCA-3')
  • 3′ sequencing primer pFBOH-rev (5'-CTGATTATGATCCTCTAGTACTTCT-3')
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

N-terminal tag AA:MHHHHHHSSGRENLYFQG.
SGC Clone ID: WDR91:PBC019-H10:C244404.
PDB 6VYC: http://www.thesgc.org/structures/6VYC/
PDB 8SHJ: https://www.rcsb.org/structure/8SHJ/
PDB 8T55: https://www.rcsb.org/structure/8T55/

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    6VYC was a gift from Cheryl Arrowsmith (Addgene plasmid # 162266 ; http://n2t.net/addgene:162266 ; RRID:Addgene_162266)
