PB-Ostir-neo
(Plasmid #161973)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 161973 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    PB
  • Backbone manufacturer
    system biosciences
  • Backbone size w/o insert (bp) 6772
  • Total vector size (bp) 9251
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Ostir-3xHA-p2a-neoR
  • Species
    Synthetic
  • Insert Size (bp)
    2670
  • Promoter CAG

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer GTGCTGTCTCATCATTTTGGCAAA
  • 3′ sequencing primer GGCAAACAACAGATGGCTGG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PB-Ostir-neo was a gift from Joanna Wysocka (Addgene plasmid # 161973 ; http://n2t.net/addgene:161973 ; RRID:Addgene_161973)
  • For your References section:

    Opposing Effects of Cohesin and Transcription on CTCF Organization Revealed by Super-resolution Imaging. Gu B, Comerci CJ, McCarthy DG, Saurabh S, Moerner WE, Wysocka J. Mol Cell. 2020 Nov 19;80(4):699-711.e7. doi: 10.1016/j.molcel.2020.10.001. Epub 2020 Oct 21. 10.1016/j.molcel.2020.10.001 PubMed 33091336
