pLV_ADRB2-mTurquoise2-iLID
(Plasmid
#161002)
-
PurposeMammalian expression of mTurquoise2-tagged iLID anchored to the plasma membrane via N-terminal fusion to ADRB2 for slow diffusion
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 161002 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepLenti 2nd gen
- Backbone size w/o insert (bp) 9240
- Total vector size (bp) 11730
-
Vector typeMammalian Expression, Lentiviral
-
Selectable markersBlasticidin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)NEB Stable
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameADRB2-mTurquoise2-iLID
-
SpeciesSynthetic
-
Insert Size (bp)2490
- Promoter EF1a
-
Tag
/ Fusion Protein
- FLAG (N terminal on insert)
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer ggagtacgtcgtctttaggt
- 3′ sequencing primer cgtcttttggcaatgtgagg (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made byThe iLID sequence was originally cloned by Dr. Brian Kuhlman's lab (Addgene plasmid #60411)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pLV_ADRB2-mTurquoise2-iLID was a gift from Sean R Collins (Addgene plasmid # 161002 ; http://n2t.net/addgene:161002 ; RRID:Addgene_161002) -
For your References section:
Optimized iLID Membrane Anchors for Local Optogenetic Protein Recruitment. Natwick DE, Collins SR. ACS Synth Biol. 2021 May 21;10(5):1009-1023. doi: 10.1021/acssynbio.0c00511. Epub 2021 Apr 12. 10.1021/acssynbio.0c00511 PubMed 33843200
