pQE-60NA-mScarlet-I
(Plasmid #160462)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 160462 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pQE-60NA
  • Backbone size w/o insert (bp) 3402
  • Total vector size (bp) 4098
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    mScarlet-I
  • Insert Size (bp)
    696
  • Promoter T5

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NcoI (unknown if destroyed)
  • 3′ cloning site NotI (unknown if destroyed)
  • 5′ sequencing primer TAGATTCAATTGTGAGCGGATAACAATTTC
  • 3′ sequencing primer TGAGGTCATTACTGGATCTATCAACAGGA
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please note: Plasmid contains T47A and Y56C mutations in Chloramphenicol acetyltransferase. These mutations are not known to affect plasmid function.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pQE-60NA-mScarlet-I was a gift from Benjamin Glick (Addgene plasmid # 160462 ; http://n2t.net/addgene:160462 ; RRID:Addgene_160462)

  • For your References section:

    A photostable monomeric superfolder GFP. Valbuena FM, Fizgerald I, Strack RL, Andruska N, Smith L, Glick BS. Traffic. 2020 May 15. doi: 10.1111/tra.12737. 10.1111/tra.12737 PubMed 32415747
