pAAV-CAG-NIR-GECO2G
(Plasmid #159605)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 159605 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pAAV-CAG
  • Backbone size w/o insert (bp) 4732
  • Total vector size (bp) 6220
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    NIR-GECO2G
  • Species
    Synthetic
  • Insert Size (bp)
    1488
  • Promoter CAG

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer CAG-Fw
  • 3′ sequencing primer WPRE-Rv
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-CAG-NIR-GECO2G was a gift from Robert Campbell (Addgene plasmid # 159605 ; http://n2t.net/addgene:159605 ; RRID:Addgene_159605)

  • For your References section:

    Improved genetically encoded near-infrared fluorescent calcium ion indicators for in vivo imaging. Qian Y, Cosio DMO, Piatkevich KD, Aufmkolk S, Su WC, Celiker OT, Schohl A, Murdock MH, Aggarwal A, Chang YF, Wiseman PW, Ruthazer ES, Boyden ES, Campbell RE. PLoS Biol. 2020 Nov 24;18(11):e3000965. doi: 10.1371/journal.pbio.3000965. eCollection 2020 Nov. 10.1371/journal.pbio.3000965 PubMed 33232322
