PB-CAG::Cytbow
(Plasmid
#158995)
-
PurposeMulticolor cytoplasmic cell labeling with a genome-integrating piggyBac transposon vector (randomly expressing tdTomato, mTurquoise2 or mEYFP upon Cre recombination)
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 158995 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepCX
-
Backbone manufacturerGenscript inc
- Backbone size w/o insert (bp) 2530
-
Vector typeMammalian Expression
-
Selectable markersH2B-EBFP2
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCytbow
-
SpeciesSynthetic
-
Insert Size (bp)7439
- Promoter CAG
-
Tag
/ Fusion Protein
- The default expressed EBFP2 is fused to H2B (N terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Unknown (unknown if destroyed)
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
PB-CAG::Cytbow was a gift from Jean Livet (Addgene plasmid # 158995 ; http://n2t.net/addgene:158995 ; RRID:Addgene_158995) -
For your References section:
Multiplex cell and lineage tracking with combinatorial labels. Loulier K, Barry R, Mahou P, Le Franc Y, Supatto W, Matho KS, Ieng S, Fouquet S, Dupin E, Benosman R, Chedotal A, Beaurepaire E, Morin X, Livet J. Neuron. 2014 Feb 5;81(3):505-20. doi: 10.1016/j.neuron.2013.12.016. 10.1016/j.neuron.2013.12.016 PubMed 24507188
