pYC2085
(Plasmid
#158721)
-
PurposeCRISPR system used for genome editing in Mycobacterium tuberculosis. Helper plasmid expresses Sth1 Cas9 and the cognate sgRNA, using hygromycin as a selection marker.
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 158721 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonecustom design
-
Vector typeBacterial Expression, CRISPR
Growth in Bacteria
-
Bacterial Resistance(s)Hygromycin, 200 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameSth1 sgRNA scaffold
-
Alt nameSth1 Cas9
-
SpeciesOther
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Unknown (unknown if destroyed)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
insert sizes: 171 bp and 3366 bp
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pYC2085 was a gift from Yi-Cheng Sun (Addgene plasmid # 158721 ; http://n2t.net/addgene:158721 ; RRID:Addgene_158721) -
For your References section:
A CRISPR-Assisted Nonhomologous End-Joining Strategy for Efficient Genome Editing in Mycobacterium tuberculosis. Yan MY, Li SS, Ding XY, Guo XP, Jin Q, Sun YC. mBio. 2020 Jan 28;11(1). pii: mBio.02364-19. doi: 10.1128/mBio.02364-19. 10.1128/mBio.02364-19 PubMed 31992616
