pBsacA
(Plasmid
#158650)
-
PurposeConstitutive transcription of sacA crRNA
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 158650 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepBSG03
- Backbone size w/o insert (bp) 6499
-
Vector typeBacterial Expression, CRISPR, Synthetic Biology ; Shuttle vector Bacillus subtilis / E. coli
-
Selectable markersKanamycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Growth instructionsSelect for growth in Bacillus subtilis using Kanamycin.
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namesacA crRNA
-
Alt namehomologous arm of sacA
-
gRNA/shRNA sequenceAATTTCTACTGTTGTAGATTCGGCCGCCTCGATTATAACAAG
-
SpeciesFrancisella tularensis subsp. novicida
-
Insert Size (bp)1409
- Promoter Pveg
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer AAATACTACCTGTCCCTTGCT (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pBsacA was a gift from Wenjing Cui (Addgene plasmid # 158650 ; http://n2t.net/addgene:158650 ; RRID:Addgene_158650)
