pEN_TT 3xFLAG-MAVS-Ala148,Ala271
(Plasmid #158633)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 158633 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEN_TTmiR2c_3xFLAG
  • Backbone manufacturer
    Addgene #83274
  • Vector type
    Gateway entry vector

Growth in Bacteria

  • Bacterial Resistance(s)
    Gentamicin, 10 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    MAVS
  • Alt name
    IPS-1
  • Alt name
    VISA
  • Species
    H. sapiens (human)
  • Mutation
    Q148A/Q271A
  • Entrez Gene
    MAVS (a.k.a. CARDIF, IPS-1, IPS1, VISA)
  • Tag / Fusion Protein
    • 3XFLAG (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SpeI (not destroyed)
  • 3′ cloning site MfeI (not destroyed)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The plasmid differs from the MAVS reference sequence at 3 position (Q93E, Q198K, and S409F). This plasmid has an additional Q148A and Q271A mutation. Gene point mutations were performed using the QuikChange Kit (Agilent Cat#200517) two times on the pEN_TT 3XFLAG-MAVS plasmid: one mutagenesis to yield pEN_TT 3XFLAG-MAVS-Q148A and a second mutagenesis to yield the double mutant.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEN_TT 3xFLAG-MAVS-Ala148,Ala271 was a gift from Kevin Janes (Addgene plasmid # 158633 ; http://n2t.net/addgene:158633 ; RRID:Addgene_158633)

  • For your References section:

    Modeling the complete kinetics of coxsackievirus B3 reveals human determinants of host-cell feedback. Lopacinski AB, Sweatt AJ, Smolko CM, Gray-Gaillard E, Borgman CA, Shah M, Janes KA. Cell Syst. 2021 Apr 21;12(4):304-323.e13. doi: 10.1016/j.cels.2021.02.004. Epub 2021 Mar 18. 10.1016/j.cels.2021.02.004 PubMed 33740397
