CMV-10xQb no wild type
(Plasmid #158205)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 158205 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    CMV-SV40
  • Backbone size w/o insert (bp) 3800
  • Vector type
    Mammalian Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    10 binding sites of QB coat protein without the WT sequence based on the oligo library experiment
  • Species
    Synthetic
  • Insert Size (bp)
    430
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer GGCACCAAAATCAACGGGACTTTCCAAAATG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CMV-10xQb no wild type was a gift from Roee Amit (Addgene plasmid # 158205 ; http://n2t.net/addgene:158205 ; RRID:Addgene_158205)

  • For your References section:

    Overcoming the design, build, test bottleneck for synthesis of nonrepetitive protein-RNA cassettes. Katz N, Tripto E, Granik N, Goldberg S, Atar O, Yakhini Z, Orenstein Y, Amit R. Nat Commun. 2021 Mar 11;12(1):1576. doi: 10.1038/s41467-021-21578-6. 10.1038/s41467-021-21578-6 PubMed 33707432
