Expression_vector RO1_1
(Plasmid #158010)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 158010 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pET-28a(+)
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    de novo designed protein RO1_1
  • Species
    Synthetic
  • Tag / Fusion Protein
    • 6x His tag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Expression_vector RO1_1 was a gift from Tanja Kortemme (Addgene plasmid # 158010 ; http://n2t.net/addgene:158010 ; RRID:Addgene_158010)

  • For your References section:

    Expanding the space of protein geometries by computational design of de novo fold families. Pan X, Thompson MC, Zhang Y, Liu L, Fraser JS, Kelly MJS, Kortemme T. Science. 2020 Aug 28;369(6507):1132-1136. doi: 10.1126/science.abc0881. 10.1126/science.abc0881 PubMed 32855341
