p12x601
(Plasmid
#157785)
-
PurposeEcoRV digestion produces 12x601 chromatin assembly construct with central TetO following PEG removal of plasmid backbone
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 157785 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCR™BluntII-TOPO®
-
Backbone manufacturerInvitrogen
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Bleocin (Zeocin), 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namepMD2.G(spei/spei)&12x601_tetO
-
SpeciesSynthetic
-
Insert Size (bp)6080
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site SpeI/EcoRV (not destroyed)
- 3′ cloning site EcoRV (not destroyed)
- 5′ sequencing primer AACAGCTATGACCATG
- 3′ sequencing primer GTAAAACGACGGCCAGT (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made bygift from Sy Redding
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
High copy plasmid (pUC-based, but medium yield)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
p12x601 was a gift from Michael Rosen (Addgene plasmid # 157785 ; http://n2t.net/addgene:157785 ; RRID:Addgene_157785) -
For your References section:
Organization of Chromatin by Intrinsic and Regulated Phase Separation. Gibson BA, Doolittle LK, Schneider MWG, Jensen LE, Gamarra N, Henry L, Gerlich DW, Redding S, Rosen MK. Cell. 2019 Oct 3;179(2):470-484.e21. doi: 10.1016/j.cell.2019.08.037. Epub 2019 Sep 19. 10.1016/j.cell.2019.08.037 PubMed 31543265
