pTarget TMEM97-P2A-mCardinal
(Plasmid
#157747)
-
PurposeExpress in mammalian cells TMEM97 and mCardianl to follow transfection efficiency using flow cytometry. mCardinal is expressed following a P2A skip peptide so it is not connected to TMEM97.
-
Depositing Lab
-
Sequence Information
Ordering
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 157747 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 * | |
* Log in to view industry pricing.
Backbone
-
Vector backbonepTarget
-
Backbone manufacturerPromega
- Backbone size w/o insert (bp) 5670
-
Vector typeMammalian Expression
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameTMEM97
-
Alt namemCardinal
-
SpeciesH. sapiens (human)
-
Insert Size (bp)1302
-
Entrez GeneTMEM97 (a.k.a. MAC30)
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer unknown (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pTarget TMEM97-P2A-mCardinal was a gift from Andrew Kruse (Addgene plasmid # 157747 ; http://n2t.net/addgene:157747 ; RRID:Addgene_157747) -
For your References section:
Identification of the gene that codes for the sigma2 receptor. Alon A, Schmidt HR, Wood MD, Sahn JJ, Martin SF, Kruse AC. Proc Natl Acad Sci U S A. 2017 Jul 3;114(27):7160-7165. doi: 10.1073/pnas.1705154114. Epub 2017 May 30. 10.1073/pnas.1705154114 PubMed 28559337
