GGDestX1-Amp
(Plasmid
#157652)
-
Purpose(Empty Backbone) Golden Gate assembly and cell-free (bacterial) expression of fusion-proteins
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 157652 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepTXTL-P70a(2)-deGFP
-
Backbone manufacturerArbor Biosciences
- Backbone size (bp) 2536
-
Modifications to backboneThe deGFP open reading frame between the start and stop codons was replaced by a BbsI-deGFP-BbsI drop-in site. Four BbsI sites in the backbone were eliminated by T > A mutations.
-
Vector typeBacterial Expression ; Cell-free Expression (E. coli sigma-70)
- Promoter OR2-OR1-Pr
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made byArbor Biosciences
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
The annotated sequence is also available at the Haynes lab Benchling site: https://benchling.com/s/seq-4Syx826a0gonKiH8Evvg.
Please visit https://doi.org/10.17504/protocols.io.brgcm3sw for the protocol.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
GGDestX1-Amp was a gift from Karmella Haynes (Addgene plasmid # 157652 ; http://n2t.net/addgene:157652 ; RRID:Addgene_157652) -
For your References section:
Rapid Single-Pot Assembly of Modular Chromatin Proteins for Epigenetic Engineering. Haynes KA, Priode JH. Methods Mol Biol. 2023;2599:191-214. doi: 10.1007/978-1-0716-2847-8_14. 10.1007/978-1-0716-2847-8_14 PubMed 36427151
