JDW 822 (pDONR221-V5-mScarlet-I-KRAS4A-WT)
(Plasmid #156405)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 156405 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pDONR221
  • Backbone size w/o insert (bp) 2545
  • Vector type
    Gateway Cloning

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Stbl3
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    human wild type KRAS4A-WT
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1405
  • GenBank ID
    NM_033360.4
  • Entrez Gene
    KRAS (a.k.a. 'C-K-RAS, C-K-RAS, CFC2, K-RAS2A, K-RAS2B, K-RAS4A, K-RAS4B, K-Ras, K-Ras 2, KI-RAS, KRAS1, KRAS2, NS, NS3, OES, RALD, RASK2, c-Ki-ras, c-Ki-ras2)
  • Tag / Fusion Protein
    • mScarlet-I (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI, SpeI (not destroyed)
  • 3′ cloning site XhoI, AscI (not destroyed)
  • 5′ sequencing primer M13F
  • 3′ sequencing primer M13R
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    JDW 822 (pDONR221-V5-mScarlet-I-KRAS4A-WT) was a gift from Joshua Wythe (Addgene plasmid # 156405 ; http://n2t.net/addgene:156405 ; RRID:Addgene_156405)
  • For your References section:

    Somatic Gain of KRAS Function in the Endothelium is Sufficient to Cause Vascular Malformations that Require MEK but not PI3K Signaling. Fish JE, Flores-Suarez CP, Boudreau E, Herman AM, Gutierrez MC, Gustafson D, DiStefano PV, Cui M, Chen Z, Berman De Ruiz K, Schexnayder TS, Ward CS, Radovanovic I, Wythe JD. Circ Res. 2020 Jun 17. doi: 10.1161/CIRCRESAHA.119.316500. 10.1161/CIRCRESAHA.119.316500 PubMed 32552404
