pLenti-PGK-RAP2A-N17-neo
(Plasmid #156179)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 156179 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pLenti PGK Neo DEST (w531-1)
  • Backbone manufacturer
    Campeau lab (addgene #19067)
  • Backbone size w/o insert (bp) 9778
  • Total vector size (bp) 8738
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    RAP2A
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    540
  • Mutation
    changed Serine 17 to Asparagine
  • GenBank ID
    NM_021033
  • Entrez Gene
    RAP2A (a.k.a. K-REV, KREV, RAP2, RbBP-30)
  • Promoter human PGK

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer PGK_F (GTGTTCCGCATTCTGCAAG)
  • 3′ sequencing primer WPRE_R (CATAGCGTAAAAGGAGCAACA)
    • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Rap2A-N17 cDNA was originally obtained as RAP2A synthetic DNA fragment, and was further mutated by site-directed mutagenesis.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

RAP2A-N17 cDNA was amplified by PCR and cloned into pENTR DTOPO and transferred by Gateway cloning into Desination vector. bioRxiv 10.1101/792077

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLenti-PGK-RAP2A-N17-neo was a gift from Roland Friedel (Addgene plasmid # 156179 ; http://n2t.net/addgene:156179 ; RRID:Addgene_156179)

  • For your References section:

    Plexin-B2 orchestrates collective stem cell dynamics via actomyosin contractility, cytoskeletal tension and adhesion. Junqueira Alves C, Dariolli R, Haydak J, Kang S, Hannah T, Wiener RJ, DeFronzo S, Tejero R, Gusella GL, Ramakrishnan A, Alves Dias R, Wojcinski A, Kesari S, Shen L, Sobie EA, Rodrigues Furtado de Mendonca JP, Azeloglu EU, Zou H, Friedel RH. Nat Commun. 2021 Oct 14;12(1):6019. doi: 10.1038/s41467-021-26296-7. 10.1038/s41467-021-26296-7 PubMed 34650052
