pJK506
(Plasmid #155382)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 155382 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    SC101
  • Total vector size (bp) 8896
  • Vector type
    Bacterial Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert 1

  • Gene/Insert name
    dCas12a (F. novicida)
  • Alt name
    dCpf1
  • Species
    Francisella tularensis subsp. novicida
  • Insert Size (bp)
    3903
  • Mutation
    D917A (nuclease-deactivating)

Gene/Insert 2

  • Gene/Insert name
    PA4-mVenus
  • Insert Size (bp)
    997

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Feng Zhang (Addgene #69973); pLPT119 (Johan Paulsson, Addgene #85526)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJK506 was a gift from Pamela Silver (Addgene plasmid # 155382 ; http://n2t.net/addgene:155382 ; RRID:Addgene_155382)
  • For your References section:

    Toward a translationally independent RNA-based synthetic oscillator using deactivated CRISPR-Cas. Kuo J, Yuan R, Sanchez C, Paulsson J, Silver PA. Nucleic Acids Res. 2020 Aug 20;48(14):8165-8177. doi: 10.1093/nar/gkaa557. 10.1093/nar/gkaa557 PubMed 32609820
