pFGAMS-mMaple3
(Plasmid #154912)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 154912 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pEGFP-N1
  • Backbone manufacturer
    Clontech
  • Total vector size (bp) 8810
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PFAS
  • Alt name
    FGAMS
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    4887
  • GenBank ID
    NM_012393
  • Entrez Gene
    PFAS (a.k.a. FGAMS, FGAR-AT, FGARAT, GATD8, PURL)
  • Promoter CMV
  • Tag / Fusion Protein
    • mMaple3 (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    The mMaple3 gene originated with Xiaowei Zhuang at Harvard and cloned from Addgene plasmid 101151.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pFGAMS-mMaple3 was a gift from Stephen Benkovic (Addgene plasmid # 154912 ; http://n2t.net/addgene:154912 ; RRID:Addgene_154912)
  • For your References section:

    Microtubule-directed transport of purine metabolons drives their cytosolic transit to mitochondria. Chan CY, Pedley AM, Kim D, Xia C, Zhuang X, Benkovic SJ. Proc Natl Acad Sci U S A. 2018 Dec 18;115(51):13009-13014. doi: 10.1073/pnas.1814042115. Epub 2018 Dec 3. 10.1073/pnas.1814042115 PubMed 30509995
