pCW-codon optimized catalytically inactive PHGDH
(Plasmid #154903)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 154903 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCW57-MCS1-P2A-MCS2
  • Backbone size w/o insert (bp) 7943
  • Total vector size (bp) 9500
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Phosphoglycerate dehydrogenase
  • Alt name
    3-phosphoglycerate dehydrogenase
  • Alt name
    PHGDH
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1629
  • Mutation
    Three mutations: D175N, R236K, H283A
  • GenBank ID
    NM_006623.4
  • Entrez Gene
    PHGDH (a.k.a. 3-PGDH, 3PGDH, HEL-S-113, NLS, NLS1, PDG, PGAD, PGD, PGDH, PHGDHD, SERA)
  • Promoter TRE

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (unknown if destroyed)
  • 3′ cloning site BamHI (unknown if destroyed)
  • 5′ sequencing primer AGCTCGTTTAGTGAACCGTCAGATC
  • 3′ sequencing primer GAACGGACGTGAAGAATGTG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCW-codon optimized catalytically inactive PHGDH was a gift from Michael Pacold (Addgene plasmid # 154903 ; http://n2t.net/addgene:154903 ; RRID:Addgene_154903)

  • For your References section:

    Limited Environmental Serine and Glycine Confer Brain Metastasis Sensitivity to PHGDH Inhibition. Ngo B, Kim E, Osorio-Vasquez V, Doll S, Bustraan S, Liang RJ, Luengo A, Davidson SM, Ali A, Ferraro GB, Fischer GM, Eskandari R, Kang DS, Ni J, Plasger A, Rajasekhar VK, Kastenhuber ER, Bacha S, Sriram RK, Stein BD, Bakhoum SF, Snuderl M, Cotzia P, Healey JH, Mainolfi N, Suri V, Friedman A, Manfredi M, Sabatini DM, Jones DR, Yu M, Zhao JJ, Jain RK, Keshari KR, Davies MA, Vander Heiden MG, Hernando E, Mann M, Cantley LC, Pacold ME. Cancer Discov. 2020 Sep;10(9):1352-1373. doi: 10.1158/2159-8290.CD-19-1228. Epub 2020 Jun 22. 10.1158/2159-8290.CD-19-1228 PubMed 32571778
