str-KDEL_Stx5LdeltaER-SBP-mCitrine
(Plasmid #154846)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 154846 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pIRES_neo3
  • Backbone manufacturer
    Clontech
  • Total vector size (bp) 6981
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Stx5 (Long isoform)
  • Alt name
    STX5
  • Alt name
    Syntaxin 5
  • Alt name
    STX5A
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1066
  • Mutation
    Changed Methionine 55 to Valine, causes loss of Stx5S expression. Changed Arginine 4, Lysine 5 and Arginine 6 to Alanine
  • GenBank ID
    NM_003164.5
  • Entrez Gene
    STX5 (a.k.a. CDG2AA, SED5, STX5A)
  • Promoter CMV
  • Tags / Fusion Proteins
    • Streptavidin Binding Protein (SBP) (C terminal on insert)
    • mCitrine (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SmaI (not destroyed)
  • 3′ cloning site SmaI (not destroyed)
  • 5′ sequencing primer IRES-F
  • 3′ sequencing primer pEGFP-all
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    str-KDEL_Stx5LdeltaER-SBP-mCitrine was a gift from Geert van den Bogaart (Addgene plasmid # 154846 ; http://n2t.net/addgene:154846 ; RRID:Addgene_154846)

  • For your References section:

    Congenital disorder of glycosylation caused by starting site-specific variant in syntaxin-5. Linders PTA, Gerretsen ECF, Ashikov A, Vals MA, de Boer R, Revelo NH, Arts R, Baerenfaenger M, Zijlstra F, Huijben K, Raymond K, Muru K, Fjodorova O, Pajusalu S, Ounap K, Ter Beest M, Lefeber D, van den Bogaart G. Nat Commun. 2021 Oct 28;12(1):6227. doi: 10.1038/s41467-021-26534-y. 10.1038/s41467-021-26534-y PubMed 34711829
