pSUI-SynP-sfGFP
(Plasmid
#154306)
-
Purpose(Empty Backbone) Expression of sfGFP under Synthetic promoter (SynP) and cloning of the sgRNA with simple screening of positive clone by fluorescence
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 154306 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepSUI-SynP-sfGFP
- Backbone size (bp) 4214
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Chloramphenicol, 25 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Cloning Information
- Cloning method Restriction Enzyme
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pSUI-SynP-sfGFP was a gift from I-Son Ng (Addgene plasmid # 154306 ; http://n2t.net/addgene:154306 ; RRID:Addgene_154306) -
For your References section:
CRISPRi-mediated Programming Essential Gene can as a Direct Enzymatic Performance Evaluation & Determination (DEPEND) System. Tan SI, Yu PJ, Ng IS. Biotechnol Bioeng. 2020 May 27. doi: 10.1002/bit.27443. 10.1002/bit.27443 PubMed 32458463
