pNAM-B1
(Plasmid #154056)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 154056 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pUAP1
  • Backbone size w/o insert (bp) 3138
  • Total vector size (bp) 3577
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    TaNAM-B1
  • Alt name
    TaGPC-B1
  • Species
    Triticum turgidum ssp. dicoccoides
  • Insert Size (bp)
    1218
  • Mutation
    Synonymous mutation at base 3257, in exon 3, to remove BbsI site
  • GenBank ID
    DQ869673.1
  • Promoter N/A

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BpiI (destroyed during cloning)
  • 3′ cloning site BpiI (destroyed during cloning)
  • 5′ sequencing primer TGCCACCTGACGTCTAAGAA
  • 3′ sequencing primer CGTTATCCCCTGATTCTGTGGATAAC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNAM-B1 was a gift from Cristobal Uauy (Addgene plasmid # 154056 ; http://n2t.net/addgene:154056 ; RRID:Addgene_154056)

  • For your References section:

    A heat-shock inducible system for flexible gene expression in cereals. Harrington SA, Backhaus AE, Fox S, Rogers C, Borrill P, Uauy C, Richardson A. Plant Methods. 2020 Oct 14;16:137. doi: 10.1186/s13007-020-00677-3. eCollection 2020. 10.1186/s13007-020-00677-3 PubMed 33072173
