pRepair-mTq2-CTNNB1
(Plasmid
#153433)
-
PurposeHomology Directed Repair construct for N-terminal tagging of hsCTNNB1 with mTurquoise2
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 153433 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepBluescript KS (+)
-
Backbone manufacturerstratagene
- Backbone size w/o insert (bp) 2965
- Total vector size (bp) 5282
-
Vector typeCRISPR ; HDR donor template
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCTNNB1 homology arms and mTurquoise2 coding sequence
-
Alt nameCTNNB1
-
SpeciesH. sapiens (human)
-
Insert Size (bp)2317
-
GenBank ID
-
Entrez GeneCTNNB1 (a.k.a. CTNNB, EVR7, MRD19, NEDSDV, armadillo)
-
Tag
/ Fusion Protein
- mTurquoise2 (N terminal on insert)
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer M13 fwd (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
mTq2 was cloned from pmTurquoise2-C1 (Dorus Gadella, Plasmid #60560)
Homology arms were cloned from genomic HEK293 DNA. Please visit https://www.biorxiv.org/content/10.1101/2020.05.28.120543v1 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pRepair-mTq2-CTNNB1 was a gift from Renee van Amerongen (Addgene plasmid # 153433 ; http://n2t.net/addgene:153433 ; RRID:Addgene_153433) -
For your References section:
Quantitative live-cell imaging and computational modeling shed new light on endogenous WNT/CTNNB1 signaling dynamics. de Man SM, Zwanenburg G, van der Wal T, Hink MA, van Amerongen R. Elife. 2021 Jun 30;10. pii: 66440. doi: 10.7554/eLife.66440. 10.7554/eLife.66440 PubMed 34190040
