Addgene

pNG1299
(Plasmid #149709)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 149709 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pUC57-Simple
  • Backbone manufacturer
    Genscript
  • Backbone size w/o insert (bp) 2710
  • Total vector size (bp) 3443
  • Vector type
    Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Triple Promoter - 12X MG Aptamer Array - Terminator construct
  • Species
    Synthetic
  • Insert Size (bp)
    727

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRV (not destroyed)
  • 3′ cloning site EcoRV (not destroyed)
  • 5′ sequencing primer GTAAAACGACGGCCAGT
  • 3′ sequencing primer CAGGAAACAGCTATGAC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNG1299 was a gift from Peter Lewis (Addgene plasmid # 149709 ; http://n2t.net/addgene:149709 ; RRID:Addgene_149709)

  • For your References section:

    Molecular basis for RNA polymerase-dependent transcription complex recycling by the helicase-like motor protein HelD. Newing TP, Oakley AJ, Miller M, Dawson CJ, Brown SHJ, Bouwer JC, Tolun G, Lewis PJ. Nat Commun. 2020 Dec 18;11(1):6420. doi: 10.1038/s41467-020-20157-5. 10.1038/s41467-020-20157-5 PubMed 33339820
