pAJ50
(Plasmid
#14918)
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 14918 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepAJ08
- Backbone size w/o insert (bp) 4515
-
Vector typeWorm Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameenhanced monomeric red fluorescent protein
-
Alt namemRFPmars
-
Alt namesynthetic RFP
-
SpeciesDictyostelium discoideum
-
Insert Size (bp)682
-
GenBank IDAY679163
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site AgeI (not destroyed)
- 3′ cloning site AvrII (not destroyed)
- 5′ sequencing primer M13 (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made byProvided in by Dr. Jakob Franke at the Dicty Stock Center, Columbia University (http://dictybase.org/stockcenter/stockcenter.html). Paper: FEBS Letters 577 (2004) 227–232. A brilliant monomeric red fluorescent protein to visualize cytoskeleton dynamics in Dictyostelium.
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
PAPER:Int J Parasitol. 2006 May 31;36(6):671-9. Epub 2006 Feb 7 Successful transgenesis of the parasitic nematode Strongyloides stercoralis requires endogenous non-coding control elements.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pAJ50 was a gift from James Lok (Addgene plasmid # 14918 ; http://n2t.net/addgene:14918 ; RRID:Addgene_14918) -
For your References section:
Strongyloides stercoralis: cell- and tissue-specific transgene expression and co-transformation with vector constructs incorporating a common multifunctional 3' UTR. Junio AB, Li X, Massey HC, Nolan TJ, Todd Lamitina S, Sundaram MV, Lok JB. Exp Parasitol. 2008 Feb . 118(2):253-65. 10.1016/j.exppara.2007.08.018 PubMed 17945217
