FCK-hCmC
(Plasmid #14897)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 14897 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    FCK(1.3)GW
  • Backbone manufacturer
    Pavel Osten
  • Backbone size w/o insert (bp) 9250
  • Vector type
    Mammalian Expression, Bacterial Expression, Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Stbl3
  • Growth instructions
    Use recombinase-free E. coli (e.g., Invitrogen's Stbl3)
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    ChR2
  • Alt name
    Channelrhodopsin-2
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1650
  • Tag / Fusion Protein
    • mCherry (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AgeI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer atgactgagaccctcccacccgtgactgaaagcgccgt
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Created with Dr. Karl Deisseroth at Stanford.

Channelrhodopsin-2/ChR2, with humanized/mammalian optimized codon usage, fused with mCherry (FCK-hCmC), containing hChR2-mCherry. Please note that the mCherry signal is faint.

For more information, see http://channelrhodopsin.org

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    FCK-hCmC was a gift from Edward Boyden (Addgene plasmid # 14897)
