pEAK-cKal7
(Plasmid #145801)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 145801 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pEAK
  • Backbone manufacturer
    Edge Biosystems
  • Backbone size w/o insert (bp) 6200
  • Total vector size (bp) 11200
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    cKalirin-7
  • Alt name
    cKal7
  • Alt name
    Kal7c
  • Species
    R. norvegicus (rat)
  • Insert Size (bp)
    5000
  • GenBank ID
    AF230644.1
  • Entrez Gene
    Kalrn (a.k.a. Duo, Hapip, Kalirin)
  • Promoter EIF2a
  • Tag / Fusion Protein
    • none (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Nco1 (destroyed during cloning)
  • 3′ cloning site Not1 (not destroyed)
  • 5′ sequencing primer CAAGCCTCAGACAGTGGTTCAAAG
  • 3′ sequencing primer CTGGGCTGGCTTACCTGCGGCCGC
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEAK-cKal7 was a gift from Betty Eipper & Richard Mains (Addgene plasmid # 145801 ; http://n2t.net/addgene:145801 ; RRID:Addgene_145801)
  • For your References section:

    Alternate promoter usage generates two subpopulations of the neuronal RhoGEF Kalirin-7. Miller MB, Yan Y, Wu Y, Hao B, Mains RE, Eipper BA. J Neurochem. 2017 Mar;140(6):889-902. doi: 10.1111/jnc.13749. Epub 2016 Sep 6. 10.1111/jnc.13749 PubMed 27465683
