pCDNA3.1 hSCN5A-L325R
(Plasmid
#145373)
-
Purposeexpresses mutant form of human Nav1.5 (L325R) found in patient with Brugada syndrome in mammalian cells
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 145373 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCDNA3.1-Zeo (+)
- Backbone size w/o insert (bp) 5015
- Total vector size (bp) 11215
-
Vector typeMammalian Expression
-
Selectable markersZeocin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namesodium voltage-gated channel alpha subunit 5
-
Alt nameNav1.5
-
Alt nameSCN5A
-
SpeciesH. sapiens (human)
-
Insert Size (bp)6200
-
Mutationchanged Leucine 325 to Arginine
-
GenBank ID
-
Entrez GeneSCN5A (a.k.a. CDCD2, CMD1E, CMPD2, HB1, HB2, HBBD, HH1, ICCD, IVF, LQT3, Nav1.5, PFHB1, SSS1, VF1)
- Promoter CMV
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer T7 Fwd (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCDNA3.1 hSCN5A-L325R was a gift from Hugues Abriel (Addgene plasmid # 145373 ; http://n2t.net/addgene:145373 ; RRID:Addgene_145373) -
For your References section:
Brugada syndrome and fever: genetic and molecular characterization of patients carrying SCN5A mutations. Keller DI, Rougier JS, Kucera JP, Benammar N, Fressart V, Guicheney P, Madle A, Fromer M, Schlapfer J, Abriel H. Cardiovasc Res. 2005 Aug 15;67(3):510-9. doi: 10.1016/j.cardiores.2005.03.024. 10.1016/j.cardiores.2005.03.024 PubMed 15890323
