pKmyc-Borg3
(Plasmid #141074)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 141074 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pKmyc
  • Backbone manufacturer
    None
  • Backbone size w/o insert (bp) 4730
  • Total vector size (bp) 5196
  • Vector type
    Mammalian Expression
  • Selectable markers
    None

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Borg3
  • Alt name
    Cdc42ep5
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
    453
  • GenBank ID
    AF164119 NM_021454
  • Entrez Gene
    Cdc42ep5 (a.k.a. 1700027J19Rik, 2010007O02Rik, Borg3, C85526, CEP5)
  • Promoter CMV
  • Tag / Fusion Protein
    • Myc (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamH1 (not destroyed)
  • 3′ cloning site EcoR1 (not destroyed)
  • 5′ sequencing primer SP6
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pKmyc-Borg3 was a gift from Ian Macara (Addgene plasmid # 141074 ; http://n2t.net/addgene:141074 ; RRID:Addgene_141074)

  • For your References section:

    Borg proteins control septin organization and are negatively regulated by Cdc42. Joberty G, Perlungher RR, Sheffield PJ, Kinoshita M, Noda M, Haystead T, Macara IG. Nat Cell Biol. 2001 Oct;3(10):861-6. doi: 10.1038/ncb1001-861. 10.1038/ncb1001-861 PubMed 11584266
