pVB006
(Plasmid #140327)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 140327 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pAN1201
  • Backbone manufacturer
    Alec Nielsen
  • Backbone size w/o insert (bp) 5043
  • Total vector size (bp) 7430
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    Tunable NOT gate and Reporter
  • Species
    Synthetic; P. fluorescens
  • Insert Size (bp)
    2387

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pVB006 was a gift from Thomas Gorochowski (Addgene plasmid # 140327 ; http://n2t.net/addgene:140327 ; RRID:Addgene_140327)

  • For your References section:

    Tunable genetic devices through simultaneous control of transcription and translation. Bartoli V, Meaker GA, di Bernardo M, Gorochowski TE. Nat Commun. 2020 Apr 29;11(1):2095. doi: 10.1038/s41467-020-15653-7. 10.1038/s41467-020-15653-7 PubMed 32350250
