p4B5-EGFP
(Plasmid #140324)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 140324 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5400
  • Total vector size (bp) 6900
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    DENV2-NGC NS4b5(10 a.a.)-NLS-eGFP
  • Alt name
    DENV GFP Reporter
  • Species
    DENV2 serotype, NGC strain
  • Insert Size (bp)
    1503
  • Mutation
    2 conservative n.t. differences near 5' end of NS4b.
  • GenBank ID
    M29095.1
  • Promoter CMV
  • Tag / Fusion Protein
    • eGFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Hind III (not destroyed)
  • 3′ cloning site Xho I (not destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer BGH polyA reverse
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    p4B5-EGFP was a gift from Alan Rothman (Addgene plasmid # 140324 ; http://n2t.net/addgene:140324 ; RRID:Addgene_140324)

  • For your References section:

    A plasmid-based reporter system for live cell imaging of dengue virus infected cells. Medin CL, Valois S, Patkar CG, Rothman AL. J Virol Methods. 2015 Jan;211:55-62. doi: 10.1016/j.jviromet.2014.10.010. Epub 2014 Oct 28. 10.1016/j.jviromet.2014.10.010 PubMed 25445884
