pEF-pIgH-ESCargo(FTV)
(Plasmid #140160)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 140160 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEF/myc/ER
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    piGH-FTVNTT-DsRed-Express2-FKBP(LV)(C22V)
  • Species
    Synthetic
  • Promoter EF-1a
  • Tag / Fusion Protein
    • ER signal sequence (MGWSCIILFLVATATGAHS) (N terminal on backbone) (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

IMPORTANT NOTE: There is an 82-bp intron after the ER signal sequence. The signal sequence will be in frame with the final product.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEF-pIgH-ESCargo(FTV) was a gift from Benjamin Glick (Addgene plasmid # 140160 ; http://n2t.net/addgene:140160 ; RRID:Addgene_140160)

  • For your References section:

    ESCargo: a regulatable fluorescent secretory cargo for diverse model organisms. Casler JC, Zajac AL, Valbuena FM, Sparvoli D, Jeyifous O, Turkewitz AP, Horne-Badovinac S, Green WN, Glick BS. Mol Biol Cell. 2020 Oct 28:mbcE20090591. doi: 10.1091/mbc.E20-09-0591. 10.1091/mbc.E20-09-0591 PubMed 33112725
