pSZT025
(Plasmid #140033)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 140033 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pUC19
  • Total vector size (bp) 6707
  • Modifications to backbone
    PCC 7002 fadD up and downstream sequences for homologous recombination; Kanamycin resistance cassette; cLac143 promoter and LacI gene under pMB2 promoter control
  • Vector type
    Bacterial Expression
  • Selectable markers
    Ampicillin

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Truncated thioesterase gene
  • Alt name
    'tesA
  • Species
    Escherichia coli
  • Insert Size (bp)
    549
  • Promoter cLac143

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer AGATGGGTGAAATCTGGTTTTAAAGTAGG
  • 3′ sequencing primer T7 terminator
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://www.biorxiv.org/content/10.1101/684944v1 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSZT025 was a gift from Peter Nixon (Addgene plasmid # 140033 ; http://n2t.net/addgene:140033 ; RRID:Addgene_140033)
  • For your References section:

    Newly discovered Synechococcus sp. PCC 11901 is a robust cyanobacterial strain for high biomass production. Wlodarczyk A, Selao TT, Norling B, Nixon PJ. Commun Biol. 2020 May 7;3(1):215. doi: 10.1038/s42003-020-0910-8. 10.1038/s42003-020-0910-8 PubMed 32382027
