P336-FBP_11
(Plasmid #139702)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 139702 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pTRANS_220d
  • Vector type
    Plant Expression, Luciferase

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    pLHB1B1:NnCPH:tSlH4, p35S_Short_TMV 5':AsNPGA:tAtug7, pCmYLCV:NnH3H:AtuOcs, pCmYLCV:NnHisps:tHsp
  • Species
    Neonothopanus nambi and Aspergillus nidulans
  • Promoter various

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AarI (destroyed during cloning)
  • 3′ cloning site AarI (destroyed during cloning)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    synthesized

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    P336-FBP_11 was a gift from Daniel Voytas (Addgene plasmid # 139702 ; http://n2t.net/addgene:139702 ; RRID:Addgene_139702)

  • For your References section:

    Building customizable auto-luminescent luciferase-based reporters in plants. Khakhar A, Starker CG, Chamness JC, Lee N, Stokke S, Wang C, Swanson R, Rizvi F, Imaizumi T, Voytas DF. Elife. 2020 Mar 25;9. pii: 52786. doi: 10.7554/eLife.52786. 10.7554/eLife.52786 PubMed 32209230
