pSP566
(Plasmid
#139500)
-
PurposeGene tagging vector to add mCherry Tag and membrane anchoring motif
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 139500 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepGT
- Backbone size w/o insert (bp) 1811
-
Vector typeYeast Expression
-
Selectable markersTRP1
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namemCherry-CaaX
-
SpeciesS. cerevisiae (budding yeast)
-
Insert Size (bp)2373
-
MutationWT
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site HincII (unknown if destroyed)
- 3′ cloning site NheI (unknown if destroyed)
- 5′ sequencing primer T3
- 3′ sequencing primer acctgacctacaggaaaga (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pSP566 was a gift from Serge Pelet (Addgene plasmid # 139500 ; http://n2t.net/addgene:139500 ; RRID:Addgene_139500) -
For your References section:
Single-particle imaging of stress-promoters induction reveals the interplay between MAPK signaling, chromatin and transcription factors. Wosika V, Pelet S. Nat Commun. 2020 Jun 23;11(1):3171. doi: 10.1038/s41467-020-16943-w. 10.1038/s41467-020-16943-w PubMed 32576833
