pSP569
(Plasmid #139499)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 139499 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pHIS
  • Backbone size w/o insert (bp) 3950
  • Vector type
    Yeast Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    pSTL1 24xPP7sl STL1 100 - 600
  • Species
    S. cerevisiae (budding yeast)
  • Insert Size (bp)
    4511
  • Mutation
    WT
  • Promoter pSTL1

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (unknown if destroyed)
  • 3′ cloning site NotI (unknown if destroyed)
  • 5′ sequencing primer TGGTCGCTATACTGCTGTCG
  • 3′ sequencing primer T7
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSP569 was a gift from Serge Pelet (Addgene plasmid # 139499 ; http://n2t.net/addgene:139499 ; RRID:Addgene_139499)

  • For your References section:

    Single-particle imaging of stress-promoters induction reveals the interplay between MAPK signaling, chromatin and transcription factors. Wosika V, Pelet S. Nat Commun. 2020 Jun 23;11(1):3171. doi: 10.1038/s41467-020-16943-w. 10.1038/s41467-020-16943-w PubMed 32576833
