p_SNIPR_target_WT
(Plasmid
#139465)
-
PurposeT7 RNAP-driven expression of the cognate SNIPR trigger RNA that is complementary to the SNIPR RNA sensor
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 139465 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepET15b
- Backbone size w/o insert (bp) 5527
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameTarget_WT
-
SpeciesOther
-
Insert Size (bp)129
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer CCTGCCACCATACCCACGC (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Cognate target for the SNIPR
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
p_SNIPR_target_WT was a gift from Alexander Green (Addgene plasmid # 139465 ; http://n2t.net/addgene:139465 ; RRID:Addgene_139465) -
For your References section:
Precise and Programmable Detection of Mutations Using Ultraspecific Riboregulators. Hong F, Ma D, Wu K, Mina LA, Luiten RC, Liu Y, Yan H, Green AA. Cell. 2020 Feb 25. pii: S0092-8674(20)30155-0. doi: 10.1016/j.cell.2020.02.011. 10.1016/j.cell.2020.02.011 PubMed 32109416
