pHD-DsRed-kkv-3::NG
(Plasmid #138960)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 138960 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pHD-DsRed
  • Backbone size w/o insert (bp) 4048
  • Vector type
    an editing vector for Drosophila

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    3' end of kkv and neon green
  • Alt name
    Chitin synthase
  • Species
    D. melanogaster (fly)
  • GenBank ID
    NM_079509.3
  • Entrez Gene
    kkv (a.k.a. Dmel_CG2666, Blimp, CG2666, CS-1, CS-1/kkv, ChSB, DmCS-1, DmeCHS1, DmeChSB, Dmel\CG2666, Kkv, blimp, chitin synthase, l(3)82Fh)
  • Tag / Fusion Protein
    • Neon Green fused to C terminus of Kkv

Cloning Information

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    The vector was obtained from Addgene ((#63166).

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://www.biorxiv.org/content/10.1101/718841v3 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pHD-DsRed-kkv-3::NG was a gift from Paul Adler (Addgene plasmid # 138960 ; http://n2t.net/addgene:138960 ; RRID:Addgene_138960)

  • For your References section:

    The localization of chitin synthase mediates the patterned deposition of chitin in developing Drosophila bristles. Adler PN. bioRxiv 2020 10.1101/718841
