PurposeExpresses RfxCas13d in mammalian cells, localized in the cytoplasm. For cloning of guide RNAs compatible with RfxCas13d. Contains a 5' direct repeat. Clone using BsmBI. F overhang aaac. R overhang aaaa
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 138148 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonelentiCRISPRv2
-
Vector typeLentiviral
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCasRx
-
SpeciesH. sapiens (human)
-
Tag
/ Fusion Protein
- NES (C terminal on insert)
Cloning Information
- Cloning method Gibson Cloning
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please visit https://doi.org/10.1101/2019.12.27.889089 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pLentiRNACRISPR_006 - hU6-DR_BsmBI-EFS-RfxCas13d-NES-2A-Puro-WPRE was a gift from Neville Sanjana (Addgene plasmid # 138148 ; http://n2t.net/addgene:138148 ; RRID:Addgene_138148) -
For your References section:
Massively parallel Cas13 screens reveal principles for guide RNA design. Wessels HH, Mendez-Mancilla A, Guo X, Legut M, Daniloski Z, Sanjana NE. Nat Biotechnol. 2020 Jun;38(6):722-727. doi: 10.1038/s41587-020-0456-9. Epub 2020 Mar 16. 10.1038/s41587-020-0456-9 PubMed 32518401
