Addgene

iLID-mRuby3-iTrkA
(Plasmid #136510)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 136510 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFP N1
  • Backbone size w/o insert (bp) 3900
  • Total vector size (bp) 6250
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    iLID mRuby3 iTrkA
  • Alt name
    TrkA
  • Species
    R. norvegicus (rat); Avena sativa
  • Insert Size (bp)
    2250
  • Entrez Gene
    Ntrk1 (a.k.a. Trk)
  • Promoter CMV

Cloning Information

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    iLID received from lab of Brian Kuhlman via Addgene (60411)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    iLID-mRuby3-iTrkA was a gift from Bianxiao Cui (Addgene plasmid # 136510 ; http://n2t.net/addgene:136510 ; RRID:Addgene_136510)

  • For your References section:

    Construction of Light-Activated Neurotrophin Receptors Using the Improved Light-Induced Dimerizer (iLID). Hope JM, Liu A, Calvin GJ, Cui B. J Mol Biol. 2020 Jun 12;432(13):3739-3748. doi: 10.1016/j.jmb.2020.04.018. Epub 2020 Apr 23. 10.1016/j.jmb.2020.04.018 PubMed 32335036
