pCS2+IMS-HyPer7
(Plasmid #136469)

• Purpose: Mammalian expression of mitochondrial intermembrane space targeted ultrasensitive hydrogen peroxide indicator HyPer7 for optical imaging
• Depositing Lab: Vsevolod Belousov
• Publication: Pak et al Cell Metab. 2020 Mar 3;31(3):642-653.e6. doi: 10.1016/j.cmet.2020.02.003.

Backbone

• Vector backbone: pCS2+
• Total vector size (bp): 5765
• Vector type: Mammalian Expression

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: HyPer7
• Insert Size (bp): 1437
• Promoter: CMV, SP6
• Tag / Fusion Protein:
  • SMAC/DIABLO

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: EcoRI (unknown if destroyed)
• 3′ cloning site: XhoI (unknown if destroyed)
• 5′ sequencing primer: ATTTAGGTGACACTATAGA
• 3′ sequencing primer: GTCATAGCTGTTTCCTG

Resource Information

• Articles Citing this Plasmid:
  • 2 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

This plasmid may exist as a multimer. This is not expected to impact the end function of the plasmid. Please refer to the Addgene Blog post on multimers for more information: https://blog.addgene.org/plasmids-101-dimers-and-multimers
