pYPQ141-ZmUbi-RZ-Aa3.8
(Plasmid
#136376)
-
Purpose(Empty Backbone) Gateway entry clone for AaCas12b sgRNA expression under ZmUbi promoter with ribozyme processing; sgRNA scaffold 3.8 is used
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 136376 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepYPQ141-ZmUbi-RZ-Lb
-
Vector typePlant Expression, CRISPR
Growth in Bacteria
-
Bacterial Resistance(s)Spectinomycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
sgRNA scaffold is from: Teng, F., Cui, T., Feng, G. et al. Repurposing CRISPR-Cas12b for mammalian genome engineering. Cell Discov 4, 63 (2018) doi:10.1038/s41421-018-0069-7
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pYPQ141-ZmUbi-RZ-Aa3.8 was a gift from Yiping Qi (Addgene plasmid # 136376 ; http://n2t.net/addgene:136376 ; RRID:Addgene_136376) -
For your References section:
CRISPR-Cas12b enables efficient plant genome engineering. Ming M, Ren Q, Pan C, He Y, Zhang Y, Liu S, Zhong Z, Wang J, Malzahn AA, Wu J, Zheng X, Zhang Y, Qi Y. Nat Plants. 2020 Mar;6(3):202-208. doi: 10.1038/s41477-020-0614-6. Epub 2020 Mar 9. 10.1038/s41477-020-0614-6 PubMed 32170285
