OSCA1.2-PP-GFP
(Plasmid #135390)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 135390 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone size w/o insert (bp) 6156
  • Total vector size (bp) 8475
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    OSCA1.2
  • Species
    A. thaliana (mustard weed)
  • Insert Size (bp)
    2313
  • GenBank ID
    NM_118333.5
  • Entrez Gene
    AT4G22120 (a.k.a. AT4G22120, F1N20.220, F1N20_220)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGFP tag connected to the gene via a precision protease cleavable linker (C terminal on insert)

Cloning Information

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Gene was human codon-optimized and synthesized by Genewiz. Precision protease cleavage linker and GFP was inserted by the lab.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    OSCA1.2-PP-GFP was a gift from Ardem Patapoutian (Addgene plasmid # 135390 ; http://n2t.net/addgene:135390 ; RRID:Addgene_135390)
  • For your References section:

    Cryo-EM structure of the mechanically activated ion channel OSCA1.2. Jojoa-Cruz S, Saotome K, Murthy SE, Tsui CCA, Sansom MS, Patapoutian A, Ward AB. Elife. 2018 Nov 1;7. pii: 41845. doi: 10.7554/eLife.41845. 10.7554/eLife.41845 PubMed 30382939
