hCMV-IE1:Lucia:bgH
(Plasmid
#135293)
-
PurposeTranscriptional unit for constitutive expression of Lucia luciferase in mammalian cells
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 135293 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneAlpha2
-
Backbone manufacturerSelf made
- Backbone size w/o insert (bp) 2327
- Total vector size (bp) 3791
-
Vector typeMammalian Expression, Luciferase, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCMV:Lucia:bGH
-
Alt nameCytomegalovirus enhancer and promoter driving the expression of the Lucia Luciferase
-
SpeciesSynthetic
-
Insert Size (bp)1464
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BsaI (destroyed during cloning)
- 3′ cloning site BsaI (destroyed during cloning)
- 5′ sequencing primer aat gag ctg att taa caa aaa ttt aac gcg
- 3′ sequencing primer ctt ttt acg gtt cct ggc ctt ttg (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Insert can be released with BsmBI for further cloning into Omega level vectors.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
hCMV-IE1:Lucia:bgH was a gift from Koen Venken (Addgene plasmid # 135293 ; http://n2t.net/addgene:135293 ; RRID:Addgene_135293) -
For your References section:
Examining multiple cellular pathways at once using multiplex hextuple luciferase assaying. Sarrion-Perdigones A, Chang L, Gonzalez Y, Gallego-Flores T, Young DW, Venken KJT. Nat Commun. 2019 Dec 13;10(1):5710. doi: 10.1038/s41467-019-13651-y. 10.1038/s41467-019-13651-y PubMed 31836712
