pMS22H-IRE
(Plasmid #133905)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 133905 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pMS22H
  • Backbone size w/o insert (bp) 5101
  • Total vector size (bp) 5183
  • Vector type
    Yeast Expression
  • Selectable markers
    TRP1

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    IRE
  • Alt name
    ferritin light chain 1 (Ftl1), mRNA
  • Species
    R. norvegicus (rat)
  • GenBank ID
    NM_022500.4
  • Entrez Gene
    Ftl1 (a.k.a. Ftl)
  • Promoter Pol III

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer TCGCCATTCAGGCTGCGGATC
  • 3′ sequencing primer ttcccccatatccaacttccaatttaatctttc
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMS22H-IRE was a gift from Sebastian Maurer (Addgene plasmid # 133905 ; http://n2t.net/addgene:133905 ; RRID:Addgene_133905)

  • For your References section:

    rec-YnH enables simultaneous many-by-many detection of direct protein-protein and protein-RNA interactions. Yang JS, Garriga-Canut M, Link N, Carolis C, Broadbent K, Beltran-Sastre V, Serrano L, Maurer SP. Nat Commun. 2018 Sep 14;9(1):3747. doi: 10.1038/s41467-018-06128-x. 10.1038/s41467-018-06128-x PubMed 30217970
