pJBL7030
(Plasmid
#133872)
-
PurposeAtz reporter plasmid
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 133872 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepUC19
- Backbone size w/o insert (bp) 3096
- Total vector size (bp) 3967
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameAtzO-sfGFP
-
SpeciesSynthetic
-
Insert Size (bp)871
- Promoter modification of pAtzDEF
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer GTTTTCCCAGTCACGAC (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
A154T mutation in superfolder GFP does not impact plasmid function
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pJBL7030 was a gift from Julius Lucks (Addgene plasmid # 133872 ; http://n2t.net/addgene:133872 ; RRID:Addgene_133872) -
For your References section:
Design and Optimization of a Cell-Free Atrazine Biosensor. Silverman AD, Akova U, Alam KK, Jewett MC, Lucks JB. ACS Synth Biol. 2020 Mar 20;9(3):671-677. doi: 10.1021/acssynbio.9b00388. Epub 2020 Mar 3. 10.1021/acssynbio.9b00388 PubMed 32078765
