ER_K20
(Plasmid #133861)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 133861 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFP-N1
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ER_K20
  • Insert Size (bp)
    2052
  • Promoter CMV
  • Tags / Fusion Proteins
    • EGFP (N terminal on insert)
    • RFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AgeI (unknown if destroyed)
  • 3′ cloning site xbaI (unknown if destroyed)
  • 5′ sequencing primer CMV-F
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    ER_K20 was a gift from Yihong Ye (Addgene plasmid # 133861 ; http://n2t.net/addgene:133861 ; RRID:Addgene_133861)

  • For your References section:

    UFMylation of RPL26 links translocation-associated quality control to endoplasmic reticulum protein homeostasis. Wang L, Xu Y, Rogers H, Saidi L, Noguchi CT, Li H, Yewdell JW, Guydosh NR, Ye Y. Cell Res. 2020 Jan;30(1):5-20. doi: 10.1038/s41422-019-0236-6. Epub 2019 Oct 8. 10.1038/s41422-019-0236-6 PubMed 31595041
